Parameters | Specifications |
Length | 2360 mm |
Width | 1200mm |
Height | 1960 mm |
Purpose | Green Fodder and Different Varieties of forages |
Recommended power sources | 5 Hp Electric Motor, 3 phase, 415v |
Type of Feed Conveyor system | Chain |
Power Transmission of Conveyor System | Chain and Sprocket |
Length of Conveyor, mm | 2100 |
Width of Conveyor, mm | 450 |
Size of Baling Chamber, mm | 400 |
Method of opening Baling Chamber | Single Acting Cylinder |
Number of Rollers in baling Chamber | 16 |
Compaction Rate, Kg/m3 | 693.28 to 721.58 |
Operating System | Hydraulic |
Operating Mechanism | Hydraulic Pump and motors with control levers |
Type of Wrapping Unit | Suitable to wrap the bale with polyethylene/ Polypropylene films of 25 - 40 microns |
Type of Wrapping | 2 Stages |
Bale Size Length, mm | 400mm |
Bale size Diameter, mm | 400mm |
Average weight of the Bale, kg | 30-35 |
Machine output, Bale /hr | 30 to 33 |
Transport Wheel | Rubber wheels - 2 numbers with good loading carrying capacity suitable to machine weight |
Tyre | Rubber Wheel with Cast Iron Body |
Type of hitch and transport arrangement | Towing Hooks Provided |
Machine weight (Dry), kg | 820 |
